C95 Casing Tubing Dimensions
| Pipe Casing Sizes, Oilfield Casing Sizes & Casing Drift Sizes |
| Outer Diameter (Casing Pipe Sizes) |
4 1/2"-20", (114.3-508mm) |
| Standard Casing Sizes |
4 1/2"-20", (114.3-508mm) |
| Thread Type |
Buttress thread casing, Long round thread casing, Short round thread casing |
| Function |
It can protect the tubing pipe. |
Oil Tube For Petroleum And Natural Gas Industries
| Name of Pipes |
Specification |
Steel Grade |
Standard |
|
|
| |
D |
(S) |
(L) |
|
|
| (mm) |
(mm) |
(m) |
| Petroleum Casing Pipe |
127-508 |
5.21-16.66 |
6-12 |
J55. M55. K55.
L80. N80. P110. |
API Spec 5CT (8) |
| Petroleum Tubing |
26.7-114.3 |
2.87-16.00 |
6-12 |
J55. M55. K55.
L80. N80. P110. |
API Spec 5CT (8) |
| Coupling |
127-533.4 |
12.5-15 |
6-12 |
J55. M55. K55.
L80. N80. P110. |
API Spec 5CT (8) |
API 5CT C95 Tubing Mechanical Properties
| Tensile Strength |
689 MPa min |
100,000 psi min |
| Yield Strength |
621 MPa min |
724 MPa max |
| |
90,000 psi min |
105,000 psi max |
| Total Elongation Under Load |
0.500 % |
- |
| Hardness |
25 Max HRC |
255 Max HBW |
