A709 Grade 50S steel
A709 Grade 50S steel
A709 Grade 50S steel
A709 Grade 50S steel

A709 Grade 50S steel

ASTM A709 Grade 50S is a high-strength, low-alloy structural steel plate utilized primarily in the manufacture of bridges. A chemical composition of iron, manganese, carbon, and other elements enable this carbon alloy to exhibit improved toughness, durability, and resistance to harsh outdoor conditions.
Product information
A709Gr50S,A709Gr.50S,A709 Grade 50S,A709 Gr 50S,Grade A709Gr50S,A709 Grade 50S

Adopt standard: ASTM A709/A709M-07
Gnee steel grade:A709 Gr.100/100W,A709 Grade 36,A709 Grade 50,A709 Grade 50S,A709 Grade 50W,A709 Grade HPS50W,A709 Grade HPS70W,A709 Grade 100,A709 Grade 100W,A709 Grade HPS100W.

A709 Grade 50S steel plate

A709 Grade 50S steel grade is a high strength low alloy structural carbon steel used in building bridge projects.

Compare A709 Gr.100, and A709 Gr.50w grade, A709 Gr.50S has a lowest yield strength in 345Mpa in usual. A 709 Gr.50S requests killed or semi-killed in manufacture.
Gnee steel supply A709 Gr.50S many years in China mainland bridge projects. We also have many stock sizes in A709 Gr.50S for urgent need to our customers. Now, we are enlarging our oversea steel market in A709 Gr.50S steel plates.

Chemical composition & Mechanical property
For more property in A709 Gr.50S steel plate, please check them in following;
A709 Grade 50S Chemical composition Heat analysis
Element Chemical %
C, max 0.23
Mn 0.50-1.60A
Si ,max 0.40
V ,max 0.15B
Nb ,max 0.05B
P ,max 0.035
S ,max 0.045
Cu ,max 0.60
Ni xma 0.45
Cr ,max 0.35
Mo ,max 0.15

A 709 Gr. 50S mechanical property
A709 Grade Thick
mm
Yield
 [MPa]
Tensile [MPa] Elongtation Min % reduction
Min
%
HB
Steel Plate Structural steel
8in[200mm] 2in[50mm] 8in[200mm] 2in[50mm]
36[250] ≤100 [250]min 400-550 20 23 20 21
  [250]min 400min 20 19
50[345] ≤100 345min 450min 18 21 18 21F
50S[345S] G 345-450HI 450minH 18 21
50W[345W]
HPS50W[HPS345W]
≤100 345min 485min 18 21 18 21J
HPS70W[HPS485W] ≤100 485min 585-760 19K
100 [690], 100W [690W],HPS100W [HPS690W] ≤65 690minB 760-895 18K L 235-293M
100 [690], 100W [690W], 65-100 620minB 690-895 16K L
