09CuPCrNi-A Steel
09CuPCrNi-A Steel
09CuPCrNi-A Steel
09CuPCrNi-A Steel

09CuPCrNi-A Steel

09CuPCrNi-A is a weather resistant steel created by alloying copper, chromium and nickel. 09CuPCrNi-A has added phosphorous which makes the material best suited for gas flue applications and for aesthetic facias. 09CuPCrNi-A steel plate is mainly used for shipping containers, steel bridges, vessels and tanks for preventing atmospheric corrosion usage.
The specifications:
09CuPCrNi-A steel is a type of weather-resistant steel that is designed to resist atmospheric corrosion and provide high strength and good toughness. It is used in various applications such as bridges, buildings, and other structures that are exposed to harsh weather conditions.

The steel contains alloy elements such as copper, chromium, and nickel, which contribute to its corrosion resistance properties. The presence of these elements forms a protective layer on the surface of the steel when exposed to the atmosphere, which helps to prevent further corrosion.

09CuPCrNi-A steel has a minimum yield strength of 345 MPa and a minimum tensile strength of 480 MPa, making it a strong and durable material for structural applications. It is typically supplied in a normalized or controlled rolled condition, which improves its toughness and ductility.
09CuPCrNi-A Chemical composition:

09CuPCrNi-A Chemical composition

Grade

The Element Max (%)



09CuPCrNi-A

C

Si

Mn

P

S

≤ 0.12

0.25-0.75

0.20-0.50

0.06-0.12

≤ 0.020

Cr

Cu

Ni

RE



0.30-1.25

0.25-0.50

0.12-0.65




09CuPCrNi-A Mechanical Properties

Grade Thickness Yield Tensile Elongation Delivery state
09CuPCrNi-A mm Min Mpa Mpa Min %
4< 345 480 24 Hot rolling
≤ 4 310 440 26 Cold rolling

09CuPCrNi-A steel plate surface treatment: Shot blasting and painting or coated.
09CuPCrNi-A steel plate application:09CuPCrNi-A steel plate is mainly used for shipping containers, steel bridges, vessels and tanks for preventing atmospheric corrosion usage.
