ASTM A529-50 Steel Channel
ASTM A529-50 Steel Channel
ASTM A529-50 Steel Channel
ASTM A529-50 Steel Channel

ASTM A529-50 Steel Channel

ASTM A529-50 carbon steel channel is stronger than common A36 steel channel for A529-50 is carbon-manganese steel. A529-50 has 50 ksi yield strength which reduces weight for the same strength.
Product introduction
ASTM A529-50 Steel Channel - U & C Channels

ASTM A529-50 carbon steel channel is stronger than common A36 steel channel for A529-50 is carbon-manganese steel. A529-50 has 50 ksi yield strength which reduces weight for the same strength. Hence, it is ideal for application where requires higher strength.

ASTM A529-50 galvanised steel channel

A529-50 steel channel types:

  • Surface treatments: black (non-treatment), hot-dip galvanized, primed.
  • A529-50 galvanized steel channel effectively resist corrosion from environments. The amount of zinc coating is customized according to your actual requirements. As to primed steel channel, it owns better corrosive resistance than zinc coating.

Applications:
Ceiling channel systems, frames or framing for machinery, equipment, walls; tracks for machines or other things; supporting parts for warehouses, shops, ordainment elements for modern buildings.

Product description:

  • Item: ASTM A529 steel channel.
  • Dimensions: UPN & UPE.
  • Web width: 80 - 200 mm.
  • Web thickness: 6 - 8.5 mm (UPN) & 4.5 - 5.2 mm (UPE).
  • Flange width: 45 - 75 mm (UPN) & 40 - 76 mm (UPE).
  • Flange thickness: 8 - 11.5 mm (UPN) & 7.4 - 9.0 mm (UPE).
  • Length: 3 m, 6 m, or as required.
  • Surface treatment: non-treatment, galvanised or primer.
  • Note: special channel sizes are available on order.
Technical data
Chemical component
Steel grade Styles Carbon, max, % Manganese, % Phosphorus, max, % Sulfur, max, % Silicon, % Copper, min, %
A529 grade 50 Steel channel 0.27 1.35 0.04 0.05 ≤0.40 0.20
Mechanical properties
Steel Steel grade Tensile strength, ksi [MPa] Yield point strength, ksi [MPa]
A529 Grade 50 70 - 100 [485 - 690] 50 [345]
ASTM A529 steel u channel sizes:
Item Depth (mm) Flange width (mm) Web thickness (mm) Flange thickness (mm) weight (kg/m)
UPN80 80 45 6 8 8.64
UPN100 100 50 6 8.5 10.6
UPN120 120 55 7 9 13.4
UPN140 140 60 7 10 16
UPN160 160 65 7.5 10.5 18.8
UPN180 180 70 8 11 22
UPN200 200 75 8.5 11.5 25.3
ASTM A529 steel c channel sizes
Item Depth (mm) Flange width (mm) Web thickness (mm) Flange thickness (mm) Weight (kg/m)
UPE80 80 40 4.5 7.4 7.05
UPE100 100 46 4.5 7.6 8.59
UPE120 120 52 4.8 7.8 10.4
UPE140 140 58 4.9 8.1 12.3
UPE160 160 64 5 8.4 14.2
UPE180 180 70 5.1 8.7 16.3
UPE200 200 76 5.2 9 18.4
