DX51D Prepainted Galvalume Steel Coil

PPGL is pre-painted galvalume steel, also known as Aluzinc steel. The galvalume & aluzinc steel coil uses the cold-rolled
steel sheet as a substrate and solidified by 55% aluminum, 43.4% zinc and 1.6% silicon at 600 °C. It combines the physical
protection and high durability of aluminum and the electrochemical protection of zinc. It is also called aluzinc steel coil.
Strong corrosion resistance, 3 times that of galvanized steel sheet.
The density of 55% aluminum is smaller than the density of zinc. When the weight is the same and the thickness of the plating
layer is the same, the area of the galvalume steel sheet is 3% or larger than that of the galvanized steel sheet.


commodity	Prepainted Steel Coil Color Coated Steel  PPGI
Techinical Standard:	JIS G3302-1998,       EN10142/10137, ASTM A653
grade	TSGCC, TDX51D  /    TDX52D  / TS250, 280GD
Types:	For general  /    drawing    use
Thickness	0.13-6.0mm(0.16-0.8mm is the most advantage thickness))
Width	Width: 610/724/820/914/1000/1200/1219/1220/1250mm
Type of  coating:	PE, SMP, PVDF
Zinc coating	Z60-150g/m2  or AZ40-100g/m2
Top painting:	5 mic. Primer + 15 mc. R. M. P.
Back painting:	5-7 mic. EP
Color:	According to RAL standard
ID coil	508mm / 610mm
Coil weight:	4--8MT
Package:	Properly packed for ocean freight exportation  in 20' ' containers
Application:	Industrial panels, roofing and siding for painting /  automobile
Price terms	FOB, CFR, CIF
Payment terms	20%TT in advance+80% TT or irrevocable 80%L/C at sight
Remarks	Insurance is all risks
	MTC 3.1  will be handed on with shipping documents
	We accept SGS certificatation test

Structure of Prepainted Galvanized Steel Coil:
* Topcoat (finishing) which provides color, pleasing appearance and appearance and a barrier film to enhance long-term durability.
* Primer coat to prevent undercutting of paint and enhance corrosion resistance.
* Pretreatment layer applied for good adhesion and to enhance corrosion resistance.
* Base steel sheet.

Application of Prepainted Galvanized Steel Coil:
1. Application of color coated steel sheet: Outdoor: roof, roof structure, surface sheet of balcony, frame of window, door, door of garage, roller shutter door, booth, Persian blinds, cabana, refrigerated wagon and so on. Indoor: door, isolater, frame of door, light steel structure of house, sliding door, folding screen, ceiling, internal decoration of toilet and elevator.
2. Refrigerator, refrigerated wagon, washing machine, electric baker, automatic selling machine, air conditioner, copying machine,cabinet, electric fan, vacuum sweeper and so on.
3. Application in transportation
Ceiling of automobile, board , internal decoration board, external shelf of automobile, carriage board, car ,instrument panel, shelf of operating platform, trolley bus, ceiling of railway, color isolator of ship, furniture of ship, floor, cargo container and so on.
4. Application in furniture and sheet metal processing
Electric warming oven, shelf of water heater, counter, shelves, chest of drawers ,chair, archive cabinet, book shelves.
