ASTM A871 / A871M steel

The ASTM A871 specification is the standard specification for high-strength low-alloy structural steel plates with atmospheric corrosion resistance used in tubular structures and poles. Grades 60 and 65 are available in the as-rolled, normalized, or quenched and tempered delivery conditions as required to achieve the specified mechanical properties.

The specifications:
Thickness: 3mm--150mm
Width: 30mm--4000mm
Length: 1000mm--12000mm
Standard: ASTM EN10025 JIS GB

A871 Grade 65 may be provided as-rolled, normalized or quenched and tempered.

A871-65 Availability
	THICKNESS	WIDTH	LENGTH
A871-65	3/16" – 1 1/4"	48" – 120"	96" – 650"

ASTM A871 Grade 65 Chemical Composition

A871-65 Steel Composition
	A871-65
Carbon	0.17-0.2%
Manganese	0.5-1.35%
Phosphorus	0.03%
Sulfur	0.03%
Silicon	0.15-0.65%
Nickel	0.4-0.5%
Chromium	0.4-0.7%
Molybdenum	0-0.1%
Copper	0.20-0.50%
Vanadium	0.01-0.1%
Columbium	0-0.05%

A871 Grade 60 Chemical composition % of the Product analysis of grade

A871 Grade 60 Chemical Composition from typeI
Grade	A871 Grade 60  The Element Max (%)
	C	Mn	P	S	Si	Ni	Cr	Mo
A871 Grade 60	0.19	0.80-1.35	0.04	0.05	0.30-0.65	0.40	0.40-0.70	--
	Cu	V	Nb
	0.25-0.40	0.02-0.10	---

A871 Grade 60 Mechanical Property

Grade	Yield strength(Mpa)Min	tensile strength(Mpa)Min
A871 Grade 60	415	520
	elongation(200mm)Min	elongation(50mm)Min
	16%	18%

1.       A871 Grade 60 Delivery Time Or Lead Time: 15-30days
2.       A871 Grade 60 Extra Service: Pretreatment (Shot Blasting, Sand Blast, Painting and Galvanized), Cutting Parts, Sample Service, Third Party inspection, UT Test and Size inspection.
3.       If you have any requirement in steel plate for A871 Grade 60, whether the new plate or stock list of material, please feel free to contact us by email of calling.
4.       If you had any question at our plate or service. Please contact our after service department to get faster reply.

High Strength Low Alloy (HSLA) Steel Plate:

Grade	C %	Mn %	P %	S %	Si %	Cu %
A871 Gr65	≤0.20	0.75-1.35	≤0.04	≤0.05	0.15-0.50	0.2-0.40
	Cr %	N %	V %	Ni %	B %	-
	0.4-0.70	–	0.01-0.10	≤0.50	–	-

Mechanical Properties Of a871 grade 65 plate:

Grade	Thickness(mm)	MinYield(Mpa)	Tensile(MPa)	Elongation (%)	Min Impact Energy
A871 Gr65	≤12mm	Min 450Mpa	Min550Mpa	17	-18℃	20J
	＞12mm	Min 450Mpa	Min 550Mpa	17	-29℃	20J
