ultra-thin non-oriented and grain oriented electrical steel sheet
ultra-thin non-oriented and grain oriented electrical steel sheet
ultra-thin non-oriented and grain oriented electrical steel sheet
ultra-thin non-oriented and grain oriented electrical steel sheet

ultra-thin non-oriented and grain oriented electrical steel sheet

Product Introduction
ultra-thin non-oriented and grain oriented electrical steel sheet for transformer core silicon steel coil
Electrical steel, also known as silicon steel, is a ferrosilicon soft magnetic alloy steel with very low carbon content, usually containing 0.5% to 4.5% silicon. The addition of silicon can increase the resistivity and maximum permeability of iron, and reduce the coercivity, iron loss and magnetic aging.

The difference between oriented silicon steel and non-oriented silicon steel

Non-oriented silicon steel: ferrosilicon alloy with very low carbon content. In the deformed and annealed steel sheet, its grains are distributed randomly. The silicon content of the alloy is 1.5% to 3.0%, or the sum of the silicon and aluminum content is 1.8% to 4.0%. The products are usually cold-rolled plates or strips, which are mainly used to manufacture motors and generators. Oriented silicon steel: It has strong directionality, the lowest iron loss value in the rolling direction, the highest magnetic permeability, and a higher magnetic induction value under a certain magnetization field. The silicon content of oriented silicon steel is about 3%. It also requires a low content of oxide inclusions in the steel and must contain certain inhibitors (MnS, A1N).
Specifications
Product Name
Electrical Steel, Lamination Steel, Silicon Electrical Steel, Silicon Steel, Relay Steel, Transformer Steel
Category
Grain-Oriented Electrical Steel; Non-oriented electrical steel
Standard
AISI, ASTM, BS, DIN, GB, JIS, EN
Thickness
0.27- 0.50 mm
Width
900-1230 mm
Brand
Gnee
Origin
China

Product Advantages

1.Stable performance
2.Excellent processing performance: High precision dimension and excellent mechanical properties make it easy to be sheared, punched and stacked by high speed punch machine. It also have good welding performance.
3.Excellent performance of Insulating coating: Uniform color, good insulation, high adhesion, excellent heat resistance and excellent processing performance

Mechanical Property
Grade
Yeild Strength
(N/mm2)
Ultra
-Tension
Strength
(N/mm2)
Ductility
(%)
Hardness
(HV1
M35W230
430
560
20.0
225
M35W250
415
550
20.5
220
M35W270
400
515
20.5
215
M35W300
360
480
21.5
195
M35W360
350
480
23.5
190
M35W440
275
420
27.5
165
M35W550
265
415
33.5
160
M50W250
430
560
19.0
230
M50W270
410
550
21.5
225
M50W290
395
545
22.5
220
M50W310
385
510
24.5
210
M50W350
350
475
26.5
190
M50W400
320
460
36.0
170
M50W470
295
425
35.0
160
M50W600
280
410
37.0
140
M50W800
285
405
38.5
135
M50W1300(D)
250
360
40.0
115

Insulating Coating
Coating types
M11
M21
Component
Chromium containing , semi organic coating
Chromium free, semi organic coating
Coating thickness
(μm)
0.7~1.5
0.8~5.0
Interlayer resistance
(Ω•mm2 /slice)
≥100
≥100
Adhesive property
Class A or class B
Class A or class B
Punching property
Excellent
Excellent
Antirust property
Excellent
Excellent
Heat resisting property
Resistant annealing at 750 C, N2 protection, for 2h
Annealing resistance in general

Product Application
Field
Purpose
Rotary machine
Large motor
Medium motor
Compressor motor
General Motors
Small precision motor
Motor for electric vehicle
The Immobilizer
High frequency working motor
Miniature power supply transformer
Instrument use transformer
Reactor
Welding machine use transformer
Power switch
Manostat
Magnetic sealing unit
Electromagnet for accelerator
