Stainless Steel 310,310S

Alloy 310 is an austenitic stainless steel that combines excellent high temperature properties with good ductility and weldability. It is typically used for elevated temperature applications as its high chromium and nickel content provide solid corrosion resistance, excellent resistance to oxidation, and superior strength in temperatures up to 2100°F. Due to its high chromium and nickel content, it is superior to 304 or 309 stainless in most environments.

Chemical Properties:

%	Cr	Ni	C	Si	Mn	P	S	Mo	Cu	Fe
310	min: 24.0 max:26.0	min: 19.0 max: 22.0	0.25	0.75	2.0	0.045	0.030	0.75	0.5	balance
310S	min: 24.0 max: 26.0	min: 19.0 max: 22.0	0.08	1.00	2.0	0.045	0.030	0.75	0.5	balance



Mechanical Properties:

Grade	Tensile Strength ksi (min.)	Yield Strength 0.2% Offset ksi (min.)	Elongation - % in 50 mm (min.)	Hardness (Brinell) MAX	Hardness (Rockwell B) MAX
310/310S	75	30	40	217	95



Physical Properties:

Denstiy lbm/in3	Coefficient of Thermal Expansion (min/in)-°F			Electrical Resistivity mW-in		Thermal Conductivity BTU/hr-ft-°F		Specific Heat BTU/lbm -°F	Magnetic Permability (annealed)1	Modules of Elasticity (annealed)2-psi
at 68 °F	at 68 – 212°F	at 68 – 932°F	at 68 – 1832°F	at 68°F	at 1200°F	at 68 – 1832°F	at 68 – 932°F	at 32 – 212°F	at 200H	in tension (E)	in shear (G)
0.29	8.8	9.5	10.5	30.7	—	10.5	10.8	0.12	1.02	29 x 106	11.2 x 106
