304 Stainless Steel
Stainless Steel
304 Stainless Steel
304 Stainless Steel

Type 304 Stainless Steel

Grade 304 stainless steel is generally regarded as the most common austenitic stainless steel. It contains high nickel content that is typically between 8 and 10.5 percent by weight and a high amount of chromium at approximately 18 to 20 percent by weight. Other major alloying elements include manganese, silicon, and carbon. The remainder of the chemical composition is primarily iron.
Product information

Grade 304 stainless steel is generally regarded as the most common austenitic stainless steel. It contains high nickel content that is typically between 8 and 10.5 percent by weight and a high amount of chromium at approximately 18 to 20 percent by weight. Other major alloying elements include manganese, silicon, and carbon. The remainder of the chemical composition is primarily iron.


The high amounts of chromium and nickel give 304 stainless steel excellent corrosion resistance. Common applications of 304 stainless steel include:

  • Appliances such as refrigerators and dishwashers
  • Commercial food processing equipment
  • Fasteners
  • Piping
  • Heat exchangers
  • Structures in environments that would corrode standard carbon steel.

Stainless steel sheet/ plates with polished surface
Stainless Steel Plate/Sheet
Product Hot rolled stainless steel plate Cold rolled stainless steel plate
Thickness 3.0mm-200mm 0.3mm-6.0mm
Standard Width

1240mm/1500mm/1800mm

/2000mm/2200mm

1000mm/1219mm/1500mm
Standard Length

2438mm/6000mm

or as client's requirement

2000mm/2439mm/3000mm

or as per client's requirement

Surface Finish No.1,HL,No.4,8K

2B,BA,No.1,No.4,No.8,8K,mirror,

checkered,embossed,hairline,

sand blast,stain brush,etching,etc.

Grade

304,304L,304J1,321,316L,316Ti,

317L,347H,310S,309S,904L,2205

304,304L,304J1,321,316L,316Ti,

317L,347H,310S,309S,904L,2205

Standard ASTM,JIS,SUS,GB,DIN ASTM,JIS,SUS,GB,DIN
Technical data

Chemical Compositionsa)

Element % Present
Carbon (C) 0.07
Chromium (Cr) 17.50 - 19.50
Manganese (Mn) 2.00
Silicon (Si) 1.00
Phosphorous (P) 0.045
Sulphur (S) 0.015b)
Nickel (Ni) 8.00 - 10.50
Nitrogen (N) 0.10
Iron (Fe) Balance


Mechanical properties

Property Value
Comprehensive Strength 210 MPa
Proof Stress 210 Min MPa
Tensile Strength 520 - 720 MPa
Elongation 45 Min%


Physical Properties

Property Value
Density 8,000 Kg/m3
Melting Point 1450 °C
Thermal Expansion 17.2 x 10-6 /K
Modulus of Elasticity 193 GPa
Thermal Conductivity 16.2W/m.K
Electrical Resistivity 0.072 x 10-6 Ω .m

FAQ
Q1: ARE YOU FACTORY OR TRADER?

A1:We've gained our Export Right and become an integrated  company of industry and trade in order to satisfy buyer's multi-request on different material and products.

Q2: WHICH MATERIAL/PRODUCTS YOU CAN PROVIDE?

A2: Stainless Steel Coils / Strips, Stainless Steel Sheets / Plates, Stainless Steel Circles / Discs, Decorative Stainless Steel Sheets.

Q3: HOW TO GET A SAMPLE?

A3: FREE samples are available for your checking and testing. And to get free samples, you need to send us you detailed receiving address (including post code) and  your DHL/FedEx/UPS account for collecting samples, courier cost will be paid in your side.
