ASTM A517 high strength steel plate

ASTM A517

The ASTM A517 specification is the Standard Specification for Pressure Vessel Plates, Alloy Steel, High-Strength, Quenched and Tempered material used in the application of fusion welded boilers and pressure vessels.  Under this specification, the plate thickness determines the grade selection and the mechanical properties.  Plates 2.5" in thickness and under, will have minimum Yield Strength of 100 ksi.  Plates over 2.5" in thickness will have a minimum Yield strength of 90 ksi.  Typical applications include unfired vessels and tanks.

Supplementary Technology:   HIC Test | NACE MR0175 | Z15 | Z25 | Z35 | S1 | S2 | S3 | S5 | S6 | S7 | S8 | S9 | S11 | S12 | S17.

Thickness: 6MM to 300MM,
Width: 1500mm to 4050mm,
Length: 3000mm to 15000mm

Gnee steel is specialized in supplying ASTM A517 steel plate. For more information of A517 steel plates, please check them in following:


ASTM A517 Grade A,A517 Gr.A,A517GrA steel plate

ASTM A517 standard specification for pressure vessel plates, alloy steel, high-strength, quenched and tempered.
The steel shall be killed and shall conform to the fine austenitic grain size requirement of Specification A20/A20M.


A517 grade A Chemical Composition
Grade	The Element Max (%)
	C	Si	Mn	P	S
A517 grade A	0.13-0.23	0.34-0.86	0.74-1.20	0.035	0.035
	Cr	Mo	B	Zr
	0.46-0.84	0.15-0.31	0.0025	0.04-0.16


Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%


Grade		A517 grade A Mechanical Property
	Thickness	Yield	Tensile	Elongation
A517 grade A	mm	Min Mpa	Mpa	Min  %
	6-65	690	795-930	16%
	65-150	620	725-930	14%



ASTM A517 Grade B,A517 Gr.B,A517GrB steel plate


A517 grade BChemical Composition
Grade	The Element Max (%)
	C	Si	Mn	P	S
A517 grade B	0.13-0.23	0.13-0.37	0.64-1.10	0.035	0.035
	Cr	Mo	B	Ti	V
	0.36-0.69	0.12-0.28	0.0005-0.005	0.01-0.05	0.02-0.09



Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%

Grade		A517 grade B Mechanical Property
	Thickness	Yield	Tensile	Elongation
A517 grade B	mm	Min Mpa	Mpa	Min  %
	6-65	690	795-930	16%
	65-150	620	725-930	14%

ASTM A517 Grade E,A517 Gr.E,A517GrE steel plate


A517 grade EChemical Composition
Grade	The Element Max (%)
	C	Si	Mn	P	S
A517 grade E	0.10-0.22	0.08-0.45	0.35-0.78	0.035	0.035
	Cr	Mo	B	Ti	V
	1.34-2.06	0.36-0.64	0.001-0.005	0.005-0.11



Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%


Grade		A517 grade E Mechanical Property
	Thickness	Yield	Tensile	Elongation
A517 grade E	mm	Min Mpa	Mpa	Min  %
	6-65	690	795-930	16%
	65-150	620	725-930	14%

ASTM A517 Grade F,A517 Gr.F,A517GrF steel plate

A517 grade FChemical Composition
Grade	The Element Max (%)
	C	Si	Mn	P	S	Cu
A517 grade F	0.08-0.22	0.13-0.37	0.55-1.10	0.035	0.035	0.12-0.53
	Cr	Mo	B	V	Ni
	0.36-0.69	0.36-0.64	0.0005-0.006	0.02-0.09	0.67-1.03



Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%


Grade		A517 grade F Mechanical Property
	Thickness	Yield	Tensile	Elongation
A517 grade F	mm	Min Mpa	Mpa	Min  %
	6-65	690	795-930	16%
	65-150	620	725-930	14%

ASTM A517 Grade H,A517 Gr.H,A517GrH steel plate

A517 grade H Chemical Composition
Grade	The Element Max (%)
	C	Si	Mn	P	S	Ni
A517 grade H	0.10-0.23	0.13-0.37	0.87-1.41	0.035	0.035	0.27-0.73
	Cr	Mo	B	V
	0.36-0.69	0.17-0.33	MIN 0.0005	0.02-0.09


Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%


Grade		A517 grade H Mechanical Property
	Thickness	Yield	Tensile	Elongation
A517 grade H	mm	Min Mpa	Mpa	Min  %
	6-65	690	795-930	16%
	65-150	620	725-930	14%


ASTM A517 Grade P,A517 Gr.P,A517GrP steel plate

A517 grade P Chemical Composition
Grade	The Element Max (%)
	C	Si	Mn	P	S	Ni
A517 grade P	0.10-0.23	0.18-0.37	0.40-0.78	0.035	0.035	1.15-1.55
	Cr	Mo	B
	0.79-1.26	0.41-0.64	0.001-0.005



Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%


Grade		A517 grade P Mechanical Property
	Thickness	Yield	Tensile	Elongation
A517 grade P	mm	Min Mpa	Mpa	Min  %
	6-65	690	795-930	16%
	65-150	620	725-930	14%

ASTM A517 Grade Q,A517 Gr.Q,A517GrQ steel plate

A517 grade Q Chemical Composition
Grade	The Element Max (%)
	C	Si	Mn	P	S	Ni
A517 grade Q	0.12-0.23	0.13-0.37	0.87-1.41	0.035	0.035	1.15-1.55
	Cr	Mo	V
	0.94-1.56	0.36-0.64	0.02-0.09



Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%

Grade		A517 grade Q Mechanical Property
	Thickness	Yield	Tensile	Elongation
A517 grade Q	mm	Min Mpa	Mpa	Min  %
	6-65	690	795-930	16%
	65-150	620	725-930	14%

ASTM A517 Grade S,A517 Gr.S,A517GrS steel plate

A517 grade S Chemical Composition
Grade	The Element Max (%)
	C	Si	Mn	P	S	Ti
A517 grade S	0.10-0.22	0.13-0.45	1.02-1.62	0.035	0.035	0.07
	Cb	Mo
	0.07	0.10-0.38


Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%


Grade		A517 grade S Mechanical Property
	Thickness	Yield	Tensile	Elongation
A517 grade S	mm	Min Mpa	Mpa	Min  %
	6-65	690	795-930	16%
	65-150	620	725-930	14%
