ASTM A106 Seamless Pressure Pipe
ASTM A106 Seamless Pressure Pipe
ASTM A106 Seamless Pressure Pipe
ASTM A106 Seamless Pressure Pipe

ASTM A106 Seamless Pressure Pipe

ASTM A106 Grade B pipe is one of the most popular seamless steel pipes applied in different industries. Not only in pipeline systems like oil and gas, water, mineral slurry transmission, but also for boiler, construction, structural purposes.
Product introduction
ASTM A106 Seamless Pressure Pipe (also known as ASME SA106 pipe) is commonly used in the construction of oil and gas refineries, power plants, petrochemical plants, boilers, and ships where the piping must transport fluids and gases that exhibit higher temperatures and pressure levels.
Gnee steel stocks a full range of A106 pipe (SA106 Pipe) in:
  • Grades B and C
  • NPS ¼” to 30” diameter
  • Schedules 10 through 160, STD, XH and XXH
  • Schedules 20 through XXH
  • Wall Thickness beyond XXH, including:
    – Up to 4” wall in 20” through 24” OD
    – Up to 3” wall in 10” through 18” OD
    – Up to 2” wall in 4” through 8” OD
Technical data
Chemical Requirements
  Grade A Grade B Grade C
Carbon max. % 0.25 0.30* 0.35*
*Manganese % 0.27 to 0.93 *0.29 to 1.06 *0.29 to 1.06
Phosphorous, max. % 0.035 0.035 0.035
Sulfur, max. % 0.035 0.035 0.035
Silicon, min.% 0.10 0.10 0.10
Chrome, max. % 0.40 0.40 0.40
Copper, max. % 0.40 0.40 0.40
Molybdenum, max. % 0.15 0.15 0.15
Nickel, max. % 0.40 0.40 0.40
Vanadium, max.% 0.08 0.08 0.08
*Unless otherwise specified by the purchaser, for each reduction of 0.01% below the specified carbon maximum, an increase of 0.06% manganese above the specified maximum will be permitted up to a maximum of 1.65% (1.35% for ASME SA106).
